Description
Introduction
Sky Whale heavy-lift electric VTOL drone airframe is specially developed for LiDAR mapping, long-range cargo delivery & transport and security & surveillance.
Heavy-lift and long-endurance
Sky Whale VTOL drone can fly 3.5 hours with 2kg payload, 2 hours with 6kg payload and 90 minutes with 10kg payload.
Specification
| MTOW | 34kg |
| Weight w/o battery and payload | 16kg |
| Wingspan | 3,914mm |
| Length | 1,920mm |
| Height | 750mm |
| Frame weight | 7.45kg |
| Max payload (battery included) | 17.7kg |
| Battery weight (Tattu 6S 32000mAh) | 7.2kg |
| Suggested max payload weight | 10kg |
| Endurance | 3.5 hours (2kg payload) / 2 hours (6kg payload) / 90min (10kg payload) |
| Cruise speed | 75-90km/h |
| Max speed | 120km/h |
| Stall speed | 57.6km/h |
| Max ascend speed | 14.4km/h |
| Max descend speed | 18km/h |
| Anti-wind capability | 43.2km/h |
| Operating Altitude(Max.) | 4,500m ASL |
